The pump is backed up to the pump-out opening with a vehicle (can be tractor or pickup). Recommended size of opening is 4' x 6' for ease of lowering pump.
Specifications:
- 150 HP Diesel Engine
- Heavy duty trailer (6,000 lb. axles)
- Large 20" dia. impeller with self cleaning blades
- Dual agitation nozzles
- 100 gallon fuel tank
|
 |
 The operator then raises the pump to a vertical position with the easily accessible controls. |
 |
Operator then lowers the pump into the Biosolids Storage Tank.
After the pump is lowered, the operator connects the PTO shaft.
You are now ready to begin pumping. ( after you connect the pump to a discharge line.) |
 |
| After pump is lowered into tank, the contents can be agitated into a homogeneous mixture with the upper and lower agitation nozzles. During the tank loading operation the bottom nozzle is continuously agitating the tank contents. |
 |
| The lower agitation nozzle can be rotated horizontally up to 200 and the upper nozzle can rotate both horizontally (200°) and vertically (60°). |
 |
 Cutting edges chop up debris and rags. Large volumes are easily pumped with the large impeller. |
|
